can bus ?

  • motamanacanic
  • motamanacanic's Avatar Topic Author
  • Offline
  • New Member
  • New Member
More
8 years 10 months ago - 8 years 10 months ago #6951 by motamanacanic
can bus ? was created by motamanacanic
i have a merc slk in today problems with the can signals
can high and can low flat-lining,and not waking up on ignition or runing, no matter where i check !
any ideas before i start disconnecting control units and keep checking the signals
as i go as this takes a lot of time, checked verus scope on other cars and all ok ????
thanks


Attachments:
Last edit: 8 years 10 months ago by Dylan. Reason: Adding attachment

Please Log in or Create an account to join the conversation.

More
8 years 10 months ago #6953 by Ben
Replied by Ben on topic Re:can bus ?
Does your service manager hate you or what ?!?

Sent from my SM-N920P using Tapatalk

Please Log in or Create an account to join the conversation.

More
8 years 10 months ago - 8 years 10 months ago #6954 by Andy.MacFadyen
Replied by Andy.MacFadyen on topic can bus ?
Only way I know is uncouple the modules one by one but you have to know which units have the 120 ohm terminating resistors as unplugging those brings the whole bus down.
" We're trying to plug a hole in the universe, what are you doing ?. "
(Walter Bishop Fringe TV show)
Last edit: 8 years 10 months ago by Andy.MacFadyen.

Please Log in or Create an account to join the conversation.

  • Dylan
  • Dylan's Avatar
  • Offline
  • Moderator
  • Moderator
  • Belgium, Europe
More
8 years 10 months ago #6975 by Dylan
Replied by Dylan on topic can bus ?
Deleted the other one since it was a double post. I'll add the attachment, funny picture :)

Please Log in or Create an account to join the conversation.

  • Tyler
  • Tyler's Avatar
  • Offline
  • Moderator
  • Moderator
  • Full time HACK since 2012
More
8 years 10 months ago #6990 by Tyler
Replied by Tyler on topic can bus ?

motamanacanic wrote: i have a merc slk in today problems with the can signals
can high and can low flat-lining,and not waking up on ignition or runing, no matter where i check !
any ideas before i start disconnecting control units and keep checking the signals
as i go as this takes a lot of time, checked verus scope on other cars and all ok ????
thanks



Bwahahaha :lol:

Are your high and low flat lined at 0V, or 2.5V? 0V would suggest a short to ground somewhere. I'd start with some resistance testing at the DLC. Find your network pins, turn the key off, and measure resistance between both pins. Should be 60-ish ohms. Then check each individual pin for resistance to ground. Both should show OL or high megaohm readings.

Please Log in or Create an account to join the conversation.

More
8 years 9 months ago #7220 by Gary B
Replied by Gary B on topic can bus ?

Tyler wrote:
Are your high and low flat lined at 0V, or 2.5V? 0V would suggest a short to ground somewhere. I'd start with some resistance testing at the DLC. Find your network pins, turn the key off, and measure resistance between both pins. Should be 60-ish ohms. Then check each individual pin for resistance to ground. Both should show OL or high megaohm readings.


I just went thru this with the Equinox, I saw that the power steering module was right by the DLC so I unplugged it and watched for the resistancd to rise to 120 ohms, then went module by module unplugging and plugging in again, till I got to the end of line resistor, which for that one was just behind the fuel tank, I left it unplugged and worked my way up to the ECM which serves as the EOL resistor for that end, with both EOL resistors off I think it read like 9 or 10 ohms between both pins.

Please Log in or Create an account to join the conversation.
